Bass restoration proc Mexico
SPECIAL EDITION FEATURES
AudioControl’s Original Digital Bass Restoration Circuit
Balanced Differential Inputs
ParaBASS® Controls for Bass Shaping
Voltage Limiter for Gain Matching
Programmable PFM Subsonic Filter Subwoofer Protection
13.5 Vrms Maximum Output Level
Lighted Epicenter Logo Flashes with Music
ACR-1 Dash Remote Included for Bass Restoration Control
Screen Printed Mexican Flag and Native Glyphs
Tricolor The Epicenter Illuminated Logo
Certificate of Authenticity
SPECIFICATIONS
INPUTS
Preamp Inputs: 2 (2 channels)
Maximum Input Level: 15 Vrms
Input Impedance: 10kO
OUTPUTS
Preamp Outputs: 2 (2 channels)
Maximum Output Level: 13.5 Vrms
Output Impedance: 150O
PERFORMANCE
Total Harmonic Distortion: 0.003%
Frequency Response: 10 Hz to 100 kHz
Signal to Noise: 130 dB
