FREQUENCY RESPONSE (HZ): 40HZ - 400HZ
RMS POWER PER CHANNEL 4Ω 175W X 1
RMS POWER PER CHANNEL 2Ω 300W X 1
RMS POWER PER CHANNEL RMS 1Ω 500W
POWER SUPPLY
- Power Supply: Full PWM
- Power Supply Threshold: 10.0V-17.0V (DC)
- Idle Current: (0.7A)
DISTORTION
- THD 4 (1KHz @4Ω): 0.05%
- S/N Ratio (A weighted @1W): -85 dBA
- S/N Ratio (A weighted @FP): -101.1 dBA
INPUT SENSITIVITY
- Low Input Level: 200mV-10.0V
- High Input Level: 200mV-10.0V
INPUT IMPEDANCE
- Low Input Level: 20 KΩ
- High Input Level: 20 KΩ
OUTPUT STAGE
- Output Impedance: 0.011Ω
- Damping Factor (50Hz @ 4Ω): >250
- Bandwidth (-3dB): 10Hz-35KHz
CROSSOVER (-12/-24 dB/Oct)
- Variable High-Pass:
- Variable Low-Pass: 40Hz-400Hz
- Variable Sub-Sonic: 10Hz-55Hz
FUSE RATINGS
- ATC: 25A
DIMENSIONS
- L x W x H: 7.7”x 4.02”x 1.4” (195.6mm x 102mm x 36mm)
