FREQUENCY RESPONSE (HZ): 70HZ-20KHZ
RMS POWER PER CHANNEL 4Ω 80W X 4 & 200W X 1
RMS POWER PER CHANNEL 2Ω 150W X 4 & 350W X 1
RMS POWER PER 2 CHANNELS BRIDGED 4Ω 300W X 2 & 200W X 1
POWER SUPPLY
- Power Supply: Full PWM
- Power Supply Threshold: 10.0V-17.0V (DC)
- Idle Current: (0.7A)
DISTORTION
- THD 4 (1KHz @4Ω): 0.5%
- S/N Ratio (A weighted @1W): -85 dBA
- S/N Ratio (A weighted @FP): -101.1 dBA
INPUT SENSITIVITY
- Low Input Level: 200mV-10.0V
- High Input Level: 200mV-10.0V
INPUT IMPEDANCE
- Low Input Level: 20 KΩ
- High Input Level: 20 KΩ
OUTPUT STAGE
- Output Impedance: 0.018Ω
- Damping Factor (50Hz @ 4Ω): >70
- Bandwidth (-3dB): 10Hz-35Hz
CROSSOVER (-12/-24 dB/Oct)
- Variable High-Pass: Flat or Fixed 70Hz
- Variable Low-Pass: 40Hz-400Hz
- Variable Sub-Sonic:
FUSE RATINGS
- ATC: 60A
DIMENSIONS
- L x W x H: 10.45”x 4.02”x 1.4” (265.6mm x 102mm x 36mm)
